BRAND	Turck
Product	PVA225P6RQ
Description	Pick-to-Light – Placement Sensor Light Grid
Internal code	IMP765717
Weight	1
Technical specification	ID 3051918 Signal and display data Purpose Pick-to-Light Function Opposed mode sensor Max. range 2000 mm Scan field 225 mm Number of beams 10 Optical resolution 25 mm Switch Function Momentary Features of color 1 Green, Can be set via DIP switches Electrical data Operating voltage 12…30 VDC Max. current consumption per color 62 mA Output function NO/NC, PNP Input type Bipolar (PNP/NPN) Response time typical < 40 ms Mechanical data Design Rectangular, PVA Dimensions 266.4 x 30 x 15 mm Housing material Metal, AL, Black Window material Acrylic, clear Electrical connection Cable with connector, M12 × 1, 0.15 m, PVC Number of cores 4
