RI-42H30S4-2B1024-12M23 - Turck Latvia Sales

BRAND	Turck
Product	RI-42H30S4-2B1024-12M23
Description	encoder
Internal code	IMP765735
Weight	1
Technical specification	İdent no. 1545228 Measuring principle Photoelectric Max. Rotation Speed 3000 U/min Rotor Moment of Inertia 150x10-6 kgm2 Starting torque 0.2 Nm Ambient temperature -40…+70 °C Operating speed 10…30 VDC No load current I0 ð 100 mA Output current ð 30 mA short circuit protection yes Output type Ascending Resolution, incremental 1024 ppr Impact compression max. 300kHz Signal level high min. UB - 3V Signal level low max. 2.5 volts Design Hollow love Flange type Mounted flash Flange diameter 100 mm Shaft type Hollow shaft Shaft diameter D [mm] 30 mm Shaft Stainless material steel Body Die-cast material frame Electrical connection Connectors, M23 radial Vibration resistance (EN 60068-2-6) 100 m/s², 10…2000 Hz Impact strength (EN 60068-2-27) 1000 m/s², 6 ms Protection class enclosure IP65 Transmitters with protection class IP65 Shipment package content Spring element, long

Please Contact Us to Order to offer competitive prices and delivery time for Turck - RI-42H30S4-2B1024-12M23 encoder number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Latvia Industrial products Market.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
