BRAND | JM Concept |
Product | TELIS 9150U1 |
Description | MODULE |
Internal code | IMP4624980 |
Technical specification | UNIVERSAL THRESHOLD CONVERTER PROGRAMMING FRONT PANEL - Graphic LCD screen - Programming joystick - USB socket on the front panel for PC communication AVAILABLE ENTRIES - 1 universal input and 1 sensor power supply - 2 current process inputs - 2 current process inputs with calculation function OUTPUTS AVAILABLE - 1 Analogue current or voltage output - 1 RT relay output - 1 RS485 modbus digital output - 1 digital output on USB socket OTHER CHARACTERISTICS - Quadruple Isolation Input/Outputs/Source Auxiliary: 3750 VAC - 20Vdc/240Vdc universal auxiliary source & 80 Vac/256 Vac - 22.5mm housing withdrawable from its DIN RAIL base or multichannel turntables - Product supplied without base - 5-year parts and labor, hardware warranty returned at the sender's expense at our head office in Brignais |
Please Contact Us to Order to offer competitive prices and delivery time for JM Concept - TELIS 9150U1 MODULE number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Latvia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
