BRAND | Nord |
Product | SK972.1-160LP/4 TF |
Description | GEARBOX |
Internal code | IMP4585137 |
Technical specification | Product designation spur gear motor Engine speed 1,465 rpm Translation 12.86 Output speed 114,000 rpm Service factor 2.10 Output torque M2 (Nm) 1,257.00 Power (kW) 15,000 Voltage (V) 400/690 Frequency (Hz) 50 Efficiency class IE3 Operating mode S1 Degree of protection motor IP55 Insulation class F Rated current 1 (AMP) 27.90 Rated current 2 (AMP) 16.10 cosine 1 0.85 Type of gearbox M4 Housing type foot housing Shaft dimension 60X120 Ventilation Open, with transport lock Oil expansion tank / oil level tank Oil expansion tank Thermal motor protection PTC thermistor, 3x155°C Circuit type triangle Terminal box position / cable entry 1/I Type of lubricant Mineral oil ISO VG 220 Class oil CLP 220 Amount of lubricant (l) 11,500 Shade 7031 blue-grey Paint type solid paint Painting specification old painting 2 Painting instructions basic (2) CE Logo Yes CCC logo no Mexico Certificate NOM No UL no CSA no DoE CC No CSA ev no High Rendimento No Korea Energy Label No Loose part oil expansion tank |
Please Contact Us to Order to offer competitive prices and delivery time for Nord - SK972.1-160LP/4 TF GEARBOX number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in Latvia Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
